收卷机
CAM TYPE WINDING MACHINE
ZD-STL系列凸轮式组合收卷机
功能及特点
本机系列是本厂最新研制成功的产品-一节能型收卷机，主电机2.2/3千瓦，采用心形凸轮代替原组合式收卷机的往复丝杆机构，往复运动全部采用滚动摩擦，机件损少，运动轻松平稳，收卷丝锭平整。采用五层两面收卷，整机长度缩短，有利于配套大型拉丝机使用。
Performance and Characteristics:
This machine,of 2.2/3kw main motor only ,is our latest and energy -. saving invention , it adopts cardioid cam replacing the reciprocating screw in combination winder , reciprocating moving wholly adopts rolling friction resulting in less attrition of parts, stable movement and flat winding spindle!The overall length is greatly shortened because of double-side winding with 5 layers each, which is very suitable for matching with a large size tape drawing machine!
|
主要技术参数Main Technical Parameters |
||||||||
|
项 目 item |
锭子层数 |
锭子数 |
丝锭宽度 |
卷丝线速度 |
主电机功率 |
收卷电机功率 |
安装尺寸（mm) |
重量(约) |
|
ZD-STL-II/150 |
5 |
150 |
200 |
30-180 |
2.2 |
7 |
4700x1500x1700 |
2800 |
|
ZD-STL-II/196 |
5 |
196 |
200 |
30-180 |
22 |
9 |
5700x1500x1700 |
3400 |
|
ZD-STL-II/240 |
5 |
240 |
200 |
30-180 |
3 |
11 |
7000×1500x1700 |
4200 |
|
ZD-STL-II/300 |
5 |
300 |
200 |
30-180 |
3 |
14 |
8500x1500x1700 |
5300 |
|
ZD-STL-II/380 |
5 |
380 |
200 |
30-180 |
3 |
17 |
10500×1500x1700 |
6600 |
|
ZD-STL-II/420 |
5 |
420 |
200 |
30-180 |
3 |
19 |
11500x1500x1700 |
7300 |
|
ZD-STL-II/480 |
5 |
480 |
200 |
30-180 |
3 |
22 |
13000x1500x1700 |
8100 |
